Introduction: The Importance of Brown Sugar Drying
Brown sugar, a natural sweetener rich in minerals like iron and manganese, retains more nutritional value than refined white sugar due to its minimal processing. However, achieving the ideal texture, moisture content, and shelf stability requires precise drying techniques. Traditional methods often rely on inconsistent heating, leading to over-drying, discoloration, or microbial growth. MeiYa’s heat pump drying technology ensures uniform drying while preserving the sugar’s natural flavor and nutrients.
Why Choose MeiYa Heat Pump Dryers for Brown Sugar?
MeiYa’s advanced heat pump systems offer significant advantages over conventional drying methods:
- Precise Temperature Control: Avoid overheating (critical for heat-sensitive sugars) with automated adjustments.
- Energy Efficiency: Reduce energy consumption by up to 70% compared to coal or electric heaters.
- Hygiene & Safety: Closed-loop design prevents contamination and eliminates open-flame risks.
- Minimal Labor: Automated cycles reduce manual monitoring.
Brown Sugar Drying Process with MeiYa Dryers
Step 1: Preparation
- Raw Material Processing: Fresh sugarcane juice is boiled to remove impurities, then simmered at controlled temperatures to evaporate excess water.
- Shaping: The thickened sugar paste is cut into small, uniform cubes or blocks for even drying.
Step 2: Two-Stage Drying Cycle
Phase 1 – Initial Heating (Temperature Rise)
- Temperature: Gradually increase to 50–55°C.
- Duration: 1 hour.
- Process: Sugar cubes are placed on trays in the drying chamber. The system circulates warm air without dehumidification to allow gentle, uniform heating.
Phase 2 – Drying with Humidity Control
- Temperature: Maintain at 55–60°C.
- Process: Activate dehumidification to remove moisture while avoiding surface cracking or melting. The system alternates between heating and humidity extraction based on real-time sensor data.
- Key Tip: Slow moisture removal prevents hardening of the sugar’s outer layer, ensuring ideal texture.
Step 3: Cooling & Packaging
- Allow dried sugar cubes to cool naturally before packaging in moisture-proof containers.
Traditional vs. MeiYa Heat Pump Drying
| Aspect | Traditional Methods | MeiYa Heat Pump Dryers |
|---|---|---|
| Temperature Stability | Inconsistent, risk of scorching | Precise control (±2°C) |
| Energy Use | High (coal/electric) | 60–70% savings |
| Product Quality | Variable color, nutrient loss | Uniform texture, retained nutrients |
| Labor | Frequent manual checks | Fully automated |
Conclusion
MeiYa heat pump dryers revolutionize brown sugar production by combining efficiency, precision, and sustainability. Whether for small-scale artisans or industrial facilities, our technology guarantees superior product quality with minimal operational costs.
Contact us to optimize your brown sugar drying process:
📧 Email: [email protected]
👤 Contact: Ray Ren
📱 WhatsApp/WeChat/Mobile: +86 133 4676 7871
MeiYa – Engineering Excellence, Naturally Preserved.


MeiYa Heat Pump Dryer Machine
- No MOQ & Customization Unlimited
- Drying + Dehumidify + Cooling
- PLC + Touch Screen Control
- 7-10 Days Delivery Time
Parameter:
| Single dryer+drying chamber | ||||
| Model | Unit | MY-03RD | MY-06RD | MY-12RD |
| Power input | KW | 5.5 | 9.5 | 19.4 |
| power supply | V/PH/HZ | 380V/3PH,50/60HZ | 380V/3PH,50/60HZ | |
| 220V/1PH,50/60HZ | ||||
| Rated current | A | 9.6A(380V),22A(220V) | 17.0 | 30.0 |
| Heating capacity | KW | 10.5 | 21.0 | 42.0 |
| Cooling capacity | KW | 7.8 | 18.0 | 32.0 |
| Dehumidity | L/H | 12.0 | 25.0 | 50.0 |
| Max temperature | ℃ | ≤75 | ≤75 | ≤75 |
| Working condition | ℃ | 0-43 | 0-43 | 0-43 |
| Electric shock protection grade | 1 | 1 | 1 | |
| Max exhause pressure | M(P)a | 30 | 30 | 30 |
| Noise | d(B(A | 75 | 75 | 75 |
| Power consumption/H | KWH | 4.8 | 8.5 | 15.0 |
| Electric heater | KW | 3.0 | 6.0 | 12.0 |
| Blowing type | / | HORIZONTAL BLOWING TYPE | ||
| Demsnssion of dryer | MM | 1650*856*1280 | 1806*1065*1280 | 2089*1260*1580 |
| Weight | KG | 180 | 285 | 480 |
Buying Guiding:
Recommend drying machine+Drying chamber sizes
| Model | Description | Drying Capacity (Per Batch) | Drying Room Size (mm) | Trolleys Number | Trays Number |
| MY-01RD-16L | All-in-one Machine | Up to 100Kg | All-in-one | 16 | |
| MY-01RD-36L | All-in-one Machine | Up to 250Kg | All-in-one | 36 | |
| MY-03RD-60L | All-in-one Machine | Up to 400Kg | All-in-one | 60 | |
| MY-03RD | 1 Unit + 1 Drying Room | Up to 700Kg | 3200*2190*2200 | 8 | 128 |
| MY-06RD | 1 Unit + 1 Drying Room | Up to 1300Kg | 6150*2190*2200 | 14 | 224 |
| MY-12RD | 1 Unit + 1 Drying Room | Up to 2000Kg | 6350*3230*2200 | 20 | 320 |
| MY-15RD | 1 Unit + 1 Drying Room | Up to 2200Kg | 6350*3230*2200 | 20 | 320 |
| MY-03RD (Double) | 2 Units + 1 Drying Room | Up to 1700Kg | 7050*2190*2200 | 16 | 256 |
| MY-06RD (Double) | 2 Units + 1 Drying Room | Up to 2500Kg | 10100*2190*2200 | 24 | 384 |
| MY-12RD (Double) | 2 Units + 1 Drying Room | Up to 4400Kg | 11860*3230*2200 | 40 | 640 |
| MY-15RD (Double) | 2 Units + 1 Drying Room | Up to 5200Kg | 11860*3230*2200 | 40 | 640 |
Our Projects:



Our Factory:

Production Processing:

Drying Machine Components:


Standard Working Modes:
- Typically 3 modes available:
- Drying Only
- Rapid temperature rise; unable to discharge moist air
- Drying + Dehumidify
- Chamber temperature rises while discharging moist air
- Cooling
- Temperature can drop to 10°C (minimum)
- Important Note:
- If temperature control becomes unstable, switch to Temperature & Humidity Mode.
- Drying Only
