Introduction: The Importance of Lily Bulb Drying
Lily bulbs, prized for their nutritional and medicinal value, require specialized processing to preserve their quality and extend shelf life. Traditional drying methods often compromise color, texture, and nutrients due to inconsistent temperature control and high energy consumption. MeiYa Air Source Heat Pump Dryers revolutionize this process by offering an energy-efficient, eco-friendly, and precise solution for producing premium dried lily bulbs. This article outlines the optimized drying workflow using MeiYa technology while highlighting its advantages over conventional approaches. .
Why Choose MeiYa Air Source Heat Pump Dryers?
MeiYa’s advanced heat pump technology ensures superior drying outcomes through:
- Energy Efficiency: Consumes up to 70% less energy than conventional electric or coal-based dryers.
- Precision Control: Maintains stable temperatures (38°C–45°C) to preserve color, texture, and nutrients.
- Automation: Reduces manual labor with programmable settings and even airflow distribution.
- Eco-Friendly: Zero emissions and reduced carbon footprint compared to fossil fuel-based systems.
Step-by-Step Drying Process with MeiYa Technology
1. Raw Material Selection
Select mature, undamaged lily bulbs with uniform size, smooth texture, and no signs of pests or blemishes. Quality raw materials are critical for producing high-grade dried products.
2. Cleaning & Slicing
Trim roots and separate bulbs into individual scales. Gently wash scales to remove dirt while avoiding damage. Discard broken or discolored pieces.
3. Blanching
Blanch scales in boiling water for 4–6 minutes until slightly softened. The optimal blanching time is determined by a crisp “snap” when bending a scale. MeiYa’s integrated boilers ensure consistent water temperatures for uniform processing.
4. Cooling & Draining
Immediately transfer blanched scales to cold water to halt cooking. Drain thoroughly to remove excess moisture, preparing them for the drying phase.
5. Loading & Pre-Treatment
Arrange scales evenly on MeiYa drying trays. For enhanced preservation, use steam sterilization (preferred over chemical methods) within the dryer’s sealed chamber to eliminate microbes.
6. Drying Phase
- Stage 1 (38°C–40°C): Initial drying for 8–10 hours to remove surface moisture.
- Stage 2 (42°C–45°C): Gradual temperature increase to dehydrate inner layers without case-hardening.
- MeiYa’s intelligent system automatically adjusts humidity and airflow, reducing total drying time to 24–30 hours (vs. 36+ hours with traditional methods).
7. Cooling & Packaging
Cool dried scales to room temperature before grading by size, color, and integrity. Package in airtight containers (e.g., 125g packs) for storage or distribution.
MeiYa vs. Traditional Drying: Key Advantages
- Temperature Stability: Avoids overheating risks common in sun-drying or coal-fired systems.
- Labor Savings: Automated trays eliminate manual rotation; no need for constant monitoring.
- Quality Consistency: Uniform drying minimizes product loss and ensures year-round output.
Conclusion
MeiYa Air Source Heat Pump Dryers redefine lily bulb processing by combining efficiency, precision, and sustainability. Whether for small-scale producers or industrial facilities, our technology guarantees premium dried lily bulbs that meet global market standards.
Contact Us Today to Optimize Your Drying Process!
📧 Email: [email protected]
📞 Contact: Ray Ren
📱 WhatsApp/WeChat/Mobile: +86 133 4676 7871
MeiYa Heat Pump Dryer Machine
- No MOQ & Customization Unlimited
- Drying + Dehumidify + Cooling
- PLC + Touch Screen Control
- 7-10 Days Delivery Time
Parameter:
| Single dryer+drying chamber | ||||
| Model | Unit | MY-03RD | MY-06RD | MY-12RD |
| Power input | KW | 5.5 | 9.5 | 19.4 |
| power supply | V/PH/HZ | 380V/3PH,50/60HZ | 380V/3PH,50/60HZ | |
| 220V/1PH,50/60HZ | ||||
| Rated current | A | 9.6A(380V),22A(220V) | 17.0 | 30.0 |
| Heating capacity | KW | 10.5 | 21.0 | 42.0 |
| Cooling capacity | KW | 7.8 | 18.0 | 32.0 |
| Dehumidity | L/H | 12.0 | 25.0 | 50.0 |
| Max temperature | ℃ | ≤75 | ≤75 | ≤75 |
| Working condition | ℃ | 0-43 | 0-43 | 0-43 |
| Electric shock protection grade | 1 | 1 | 1 | |
| Max exhause pressure | M(P)a | 30 | 30 | 30 |
| Noise | d(B(A | 75 | 75 | 75 |
| Power consumption/H | KWH | 4.8 | 8.5 | 15.0 |
| Electric heater | KW | 3.0 | 6.0 | 12.0 |
| Blowing type | / | HORIZONTAL BLOWING TYPE | ||
| Demsnssion of dryer | MM | 1650*856*1280 | 1806*1065*1280 | 2089*1260*1580 |
| Weight | KG | 180 | 285 | 480 |
Buying Guiding:
Recommend drying machine+Drying chamber sizes
| ITEM | DESCRIPTION | PRODUCT CAPACITY | DRYING CHAMBER SIZE |
| 1 | One unit MY-03RD+Drying chamer | (300-600)kg/batch | 3200*2190*2200 (mm) |
| 2 | One unit MY-06RD+Drying chamer | (600-1000)kg/batch | 6150*2190*2200 (mm) |
| 3 | One unit MY-12RD+Drying chamer | (1300-2500)kg/batch | 6350*3230*2200 (mm) |
| 4 | Two unit MY-03RD+Drying chamer | (1200-2000)kg/batch | 7050*2190*2200 (mm) |
| 5 | Two unit MY-06RD+Drying chamer | (1500-2500)kg/batch | 10100*2190*2200 (mm) |
| 6 | Two unit MY-12RD+Drying chamer | (3500-5000)kg/batch | 11860*3230*2200 (mm) |
Our Projects:
Our Factory:
Production Processing:
Drying Machine Components:
Standard Working Modes:
- Typically 3 modes available:
- Drying Only
- Rapid temperature rise; unable to discharge moist air
- Drying + Dehumidify
- Chamber temperature rises while discharging moist air
- Cooling
- Temperature can drop to 10°C (minimum)
- Important Note:
- If temperature control becomes unstable, switch to Temperature & Humidity Mode.
- Drying Only
