Introduction: The Importance of Fig Drying
Fresh figs are highly perishable, making drying a critical step to extend shelf life while preserving their natural sweetness, nutrients, and chewy texture. Traditional sun-drying or conventional dryers often compromise quality due to inconsistent temperature control, energy inefficiency, and exposure to contaminants. MeiYa’s advanced Air Source Heat Pump Dryer revolutionizes this process with precision, energy savings, and automation—ensuring premium-quality dried figs for commercial and artisanal producers.
Why Choose MeiYa Heat Pump Dryers?
MeiYa’s technology stands out with these advantages:
- Energy Efficiency: Absorbs ambient heat to generate thermal energy (no combustion), reducing energy consumption by 60% compared to traditional dryers.
- Precision Control: Intelligent temperature and humidity management ensures uniform drying without over-drying or case-hardening.
- Eco-Friendly: Zero emissions align with sustainable production goals.
- Low Labor Costs: Fully automated cycles minimize manual intervention.
Step-by-Step Fig Drying Process with MeiYa Dryers
Stage 1: Color Setting & Pre-Drying
• Temperature: Start at 30–40°C for 6–8 hours to gently remove surface moisture and lock in natural color.
• Key Action: Gradually increase to 60°C in the final 2 hours to stabilize pigmentation.
Stage 2: Intensive Moisture Removal
• Temperature: Maintain 55°C for ~15 hours.
• Humidity Control: Reduce relative humidity (RH) to 40% using automated dehumidification. This phase removes bulk internal moisture while preserving texture.
Stage 3: Final Drying & Conditioning
• Temperature: Lower to 40°C for ~10 hours.
• Target RH: 25% to achieve ideal moisture content (15–20% in dried figs).
• Result: Uniformly soft, non-sticky figs with concentrated flavor.
Traditional vs. MeiYa Heat Pump Drying
| Factor | Traditional Methods | MeiYa Heat Pump Dryer |
| Temperature Control | Unstable, risk of scorching | Precise (±1°C), multi-stage logic |
| Energy Use | High (fuel/electricity-dependent) | 60% lower energy consumption |
| Labor | Constant monitoring required | Fully automated cycles |
| Consistency | Variable quality due to outdoor factors | Batch-to-batch uniformity |
Conclusion: Elevate Your Fig Drying with MeiYa
MeiYa’s heat pump dryers deliver unmatched efficiency and quality for fig processing. By combining advanced heat recovery, smart humidity management, and customizable programs, our systems ensure maximum nutrient retention, vibrant color, and extended shelf life—all while slashing operational costs.
Contact MeiYa Experts Today! • Email: [email protected]
• Sales Manager: Ray Ren
• Mobile/WhatsApp/WeChat: +86 133 4676 7871
Let MeiYa empower your production with cutting-edge drying solutions tailored to your needs.
MeiYa – Innovating Sustainability in Food Processing.
MeiYa Heat Pump Dryer Machine
- No MOQ & Customization Unlimited
- Drying + Dehumidify + Cooling
- PLC + Touch Screen Control
- 7-10 Days Delivery Time
Parameter:
| Single dryer+drying chamber | ||||
| Model | Unit | MY-03RD | MY-06RD | MY-12RD |
| Power input | KW | 5.5 | 9.5 | 19.4 |
| power supply | V/PH/HZ | 380V/3PH,50/60HZ | 380V/3PH,50/60HZ | |
| 220V/1PH,50/60HZ | ||||
| Rated current | A | 9.6A(380V),22A(220V) | 17.0 | 30.0 |
| Heating capacity | KW | 10.5 | 21.0 | 42.0 |
| Cooling capacity | KW | 7.8 | 18.0 | 32.0 |
| Dehumidity | L/H | 12.0 | 25.0 | 50.0 |
| Max temperature | ℃ | ≤75 | ≤75 | ≤75 |
| Working condition | ℃ | 0-43 | 0-43 | 0-43 |
| Electric shock protection grade | 1 | 1 | 1 | |
| Max exhause pressure | M(P)a | 30 | 30 | 30 |
| Noise | d(B(A | 75 | 75 | 75 |
| Power consumption/H | KWH | 4.8 | 8.5 | 15.0 |
| Electric heater | KW | 3.0 | 6.0 | 12.0 |
| Blowing type | / | HORIZONTAL BLOWING TYPE | ||
| Demsnssion of dryer | MM | 1650*856*1280 | 1806*1065*1280 | 2089*1260*1580 |
| Weight | KG | 180 | 285 | 480 |
Buying Guiding:
Recommend drying machine+Drying chamber sizes
| ITEM | DESCRIPTION | PRODUCT CAPACITY | DRYING CHAMBER SIZE |
| 1 | One unit MY-03RD+Drying chamer | (300-600)kg/batch | 3200*2190*2200 (mm) |
| 2 | One unit MY-06RD+Drying chamer | (600-1000)kg/batch | 6150*2190*2200 (mm) |
| 3 | One unit MY-12RD+Drying chamer | (1300-2500)kg/batch | 6350*3230*2200 (mm) |
| 4 | Two unit MY-03RD+Drying chamer | (1200-2000)kg/batch | 7050*2190*2200 (mm) |
| 5 | Two unit MY-06RD+Drying chamer | (1500-2500)kg/batch | 10100*2190*2200 (mm) |
| 6 | Two unit MY-12RD+Drying chamer | (3500-5000)kg/batch | 11860*3230*2200 (mm) |
Our Projects:
Our Factory:
Production Processing:
Drying Machine Components:
Standard Working Modes:
- Typically 3 modes available:
- Drying Only
- Rapid temperature rise; unable to discharge moist air
- Drying + Dehumidify
- Chamber temperature rises while discharging moist air
- Cooling
- Temperature can drop to 10°C (minimum)
- Important Note:
- If temperature control becomes unstable, switch to Temperature & Humidity Mode.
- Drying Only
