MeiYa Heat Pump Dryer: The Professional Solution for Chestnuts Drying

Introduction: The Importance of Chestnuts Drying

Chestnuts, often hailed as the “King of Dried Fruits” and known abroad as “Ginseng Fruit,” are highly nutritious nuts rich in carbohydrates (up to 70.1% sugar and starch), protein, vitamins (especially vitamin C and B1), and minerals. In traditional Chinese medicine, chestnuts are valued for their kidney‑tonifying, spleen‑strengthening, and overall health‑promoting properties. To preserve their flavor, texture, and nutritional value for extended storage and consumption, proper drying is essential. Traditional sun‑drying or coal‑fired methods are slow, weather‑dependent, and prone to contamination. MeiYa’s heat pump drying technology offers a controlled, efficient, and hygienic solution that ensures premium‑quality dried chestnuts year‑round.

---

Why Choose MeiYa Heat Pump Dryers for Chestnuts?

Conventional drying approaches (e.g., coal‑fired or simple electric heating) are inefficient, polluting, and labor‑intensive. MeiYa’s advanced heat‑pump system provides a modern, sustainable alternative:

1. High Energy Efficiency
   By extracting heat from ambient air, MeiYa dryers consume significantly less electricity than conventional systems, reducing operating costs by up to 60–70%.
2. Precise Temperature Control
   Chestnuts require a stable, high‑temperature drying profile (around 75°C) to achieve the desired moisture reduction without damaging the kernel. MeiYa dryers maintain exact temperature settings (±1–2°C), ensuring uniform dehydration.
3. Fully Automated Operation
   Once the drying parameters are set, the system runs autonomously, eliminating the need for constant manual supervision and cutting labor expenses.
4. Hygienic & Eco‑Friendly
   The closed drying chamber protects chestnuts from dust, insects, and external pollutants. With no combustion or emissions, MeiYa dryers support clean, sustainable production.
5. Continuous Dehumidification
   The system features continuous moisture removal during drying, which is critical for achieving the target moisture content (around 30%) that allows the inner skin (pellicle) to separate easily from the kernel.
6. Weather‑Independent Performance
   Unlike sun‑drying, MeiYa dryers operate consistently regardless of outdoor conditions, ensuring batch‑to‑batch consistency and uninterrupted processing.

---

Step‑by‑Step Chestnuts Drying Process with MeiYa Dryers

Step 1: Pre‑drying Preparation

• Cleaning & Grading: Wash fresh chestnuts thoroughly to remove impurities, then sort them by size for uniform drying.
• Flavoring (Optional): For flavored chestnuts, prepare a boiling solution with 80g star anise, 50g cinnamon, 15g cloves, 15g Sichuan pepper, 20g licorice root, 400g salt, 250g sugar, and 10kg water. Boil for 30 minutes, then add the chestnuts and cook until tender. This step helps the flavor penetrate the tough outer shell.
• Rinsing: Rinse the boiled chestnuts with clean water to remove surface seasoning residue.

Step 2: Drying Cycle

• Loading: Spread the prepared chestnuts evenly on stainless‑steel trays and load them into the MeiYa drying chamber.
• Drying Parameters: – Temperature: Set directly to 75°C (chestnuts tolerate high temperatures well).
  – Time: 6 hours of continuous drying.
  – Dehumidification: Enable continuous moisture removal throughout the cycle.
• Process: The steady 75°C heat, combined with continuous dehumidification, gradually reduces the moisture content. When the moisture drops to about 30%, the inner pellicle separates from the kernel, making the nuts easy to peel while keeping the kernel intact and pleasantly moist.

Step 3: Cooling & Packaging

• Natural Cooling: Allow the dried chestnuts to cool inside the chamber or in a clean, dry environment.
• Quality Check: Verify that the pellicle separates easily, the kernel remains whole, and the moisture is uniform.
• Packaging: Pack in vacuum‑sealed or moisture‑proof bags for storage or sale.

---

Traditional vs. MeiYa Heat Pump Drying: A Quick Comparison

Aspect	Traditional Methods	MeiYa Heat Pump Dryers
Energy Source	Coal, wood, or sunlight	Ambient air heat + minimal electricity
Temperature Control	Unstable, manual adjustment	Precise, stable (75°C ±1–2°C)
Drying Time	Longer, weather‑dependent	Consistent 6‑hour cycle
Operating Cost	High fuel costs, labor‑intensive	Up to 70% energy savings, low labor
Labor Need	Constant stoking, turning, monitoring	Fully automated
Product Quality	Variable, risk of mold or uneven drying	Uniform moisture, easy pellicle separation
Environmental Impact	Smoke, dust, pollution	Zero emissions, clean process
Consistency	Batch‑to‑batch variability	High repeatability

---

Conclusion

MeiYa heat pump dryers provide a reliable, energy‑efficient, and eco‑friendly solution for chestnut processing. By combining advanced heat‑pump technology with precise high‑temperature control and continuous dehumidification, they deliver high‑quality dried chestnuts with easy‑to‑remove pellicles and intact kernels in a consistent 6‑hour cycle, while significantly reducing energy consumption and labor costs compared to traditional drying methods.

Upgrade your chestnut drying operation with MeiYa—where innovation meets nut‑processing excellence.

---

Contact Us for a Customized Solution:
📧 Email: [email protected]
👤 Contact: Ray Ren
📱 WhatsApp/WeChat/Mobile: +86 133 4676 7871

---

MeiYa – Engineering Smarter Drying for a Healthier World.

MeiYa Heat Pump Dryer Machine

1. No MOQ & Customization Unlimited
2. Drying + Dehumidify + Cooling
3. PLC + Touch Screen Control
4. 7-10 Days Delivery Time

Parameter:

Single dryer+drying chamber
Model	Unit	MY-03RD	MY-06RD	MY-12RD
Power input	KW	5.5	9.5	19.4
power supply	V/PH/HZ	380V/3PH,50/60HZ	380V/3PH,50/60HZ
		220V/1PH,50/60HZ
Rated current	A	9.6A(380V),22A(220V)	17.0	30.0
Heating capacity	KW	10.5	21.0	42.0
Cooling capacity	KW	7.8	18.0	32.0
Dehumidity	L/H	12.0	25.0	50.0
Max temperature	℃	≤75	≤75	≤75
Working condition	℃	0-43	0-43	0-43
Electric shock protection grade		1	1	1
Max exhause pressure	M(P)a	30	30	30
Noise	d(B(A	75	75	75
Power consumption/H	KWH	4.8	8.5	15.0
Electric heater	KW	3.0	6.0	12.0
Blowing type	/	HORIZONTAL BLOWING TYPE
Demsnssion of dryer	MM	1650*856*1280	1806*1065*1280	2089*1260*1580
Weight	KG	180	285	480

Buying Guiding:

Recommend drying machine+Drying chamber sizes

Model	Description	Drying Capacity (Per Batch)	Drying Room Size (mm)	Trolleys Number	Trays Number
MY-01RD-16L	All-in-one Machine	Up to 100Kg	All-in-one		16
MY-01RD-36L	All-in-one Machine	Up to 250Kg	All-in-one		36
MY-03RD-60L	All-in-one Machine	Up to 400Kg	All-in-one		60
MY-03RD	1 Unit + 1 Drying Room	Up to 700Kg	3200*2190*2200	8	128
MY-06RD	1 Unit + 1 Drying Room	Up to 1,300Kg	6150*2190*2200	14	224
MY-12RD	1 Unit + 1 Drying Room	Up to 2,000Kg	6350*3230*2200	20	320
MY-15RD	1 Unit + 1 Drying Room	Up to 2,200Kg	6350*3230*2200	20	320
MY-03RD (Double)	2 Units + 1 Drying Room	Up to 1,700Kg	7050*2190*2200	16	256
MY-06RD (Double)	2 Units + 1 Drying Room	Up to 2,500Kg	10100*2190*2200	24	384
MY-12RD (Double)	2 Units + 1 Drying Room	Up to 4,400Kg	11860*3230*2200	40	640
MY-15RD (Double)	2 Units + 1 Drying Room	Up to 5,200Kg	11860*3230*2200	40	640
MY-25RD (Double)	2 Units + 1 Drying Room	Up to 10,000Kg	13520*6070*2200	48	1920

Our Projects:

Our Factory:

Production Processing:

Drying Machine Components:

Standard Working Modes:

• Typically ​3 modes available:
  • ​Drying Only
    • Rapid temperature rise; ​unable to discharge moist air
  • ​Drying + Dehumidify
    • Chamber temperature rises ​while discharging moist air
  • ​Cooling
    • Temperature can ​drop to 10°C (minimum)
  • Important Note:
    • If temperature control becomes unstable, ​switch to Temperature & Humidity Mode.

---
